Pan & Tilt Positioners

HPA Subsea offer a comprehensive range of precision built pan and tilt positioners, designed to position cameras, lights and other sonar equipment with the utmost protection against the harshest of subsea environments. Our positioners are perfectly suited for manned submersibles, ROVs and other subsea platforms.

We can offer you a wide range of units with advanced features including high-torque, continuous-rotation, electric single-axis rotation with position feedback, for applications down to 6000m. With proven reliability over many years, our pan & tilt positioners are robust, lightweight and extremely compact.

Typical features and benefits include:

Lightweight and extremely compact
High-torque
Continuous-rotation
Submersibles, ROVs, subsea platforms
Single-axis rotation with position feedback
Robust built and proven
Applications down to 6000m

From our comprehensive range of pan and tilt positioners, please see a selection featured below. For full technical specifications and information about each product, please click on the PDF icon.

Miniature Pan & Tilt Positioner

Hammerhead

Specification sheet

Depth Rating - 2,000m (6,600ft)
Operating Temperature 0ºC to 40ºC
Ethernet Ports - 12 x Gigabit
Size - 5.46in (138.5mm) Dia. x 14.5in (368mm)
Weight - 16 lbs (7.25kg) in air, 4 lbs (1.8kg) in seawater
Housing Material - 6061-T6 AHC black aluminum

Miniature Pan & Tilt Positioner / XT

Hammerhead XT

Specification sheet

Depth Rating - 2,000m (6,600ft)
Operating Temperature - -10ºC to 40ºC
Pressure Port Thread - 7/16” -20 UNF or 1/4” -18 NPT
Size - 163mm L x 33mm dia.
Weight - 500g (in air); 300g (in saltwater)
Housing Material - 316 stainless steel

Miniature Pan & Tilt Positioner / XTR

Hammerhead XTR

Specification sheet

Input Voltage - 8–30VDC
Output - Serial RS232 or Ethernet (both onboard)
Size - 90.5mm L x 51mm W x 19mm H
Ground Fault Measurement - 2 channels, 350 VDC max
Leak Detection Measurements - 8 independent self-checking, fail-safe channels
Operating Temperature - -10ºC to 40ºC

Miniature Pan & Tilt Positioner / HHR

Hammerhead HHR

Specification sheet

Input Voltage - 8–30VDC
Output - Serial RS232 or Ethernet (both onboard)
Size - 90.5mm L x 51mm W x 19mm H
Ground Fault Measurement - 2 channels, 350 VDC max
Leak Detection Measurements - 8 independent self-checking, fail-safe channels
Operating Temperature - -10ºC to 40ºC
